1.Main Technical Parameters
Model | 1200 |
Printing Colors | 8 color |
Max. material width | 1200mm |
Suitable material | Film, Paper,nonwoven fabric and foil |
Max. printing length | 191mm-1270mm |
Mechanical speed | 100m/min |
Printing speed | 10-80m/min |
Anilox type | Ceramic anilox |
Register precision | Longitude:±0.15mm Transverse:±0.15mm |
Rewinding&unwinding diameter | 600mm/customize |
Automatic tension control | 2-30kg |
Total power | 45kw |
Total weight | 6500kg |
Size | 4.8M*2.5M*3.5M |
2.Comprehensive Description We specialize in gravure and flexographic printing machine, with independent research and development capabilities. 8 colors stacked type high speed flexographic printing machine is our top products. It brings together all of our technological advantages, combining the strengths of gravure and flexo printing: easy platemaking, high-precision, high speed, fast drying (UV or IR), support water-based ink, widely used and so on. We have the capability to manufacture 1-8 colors & 600-2000mm flexographic printing machine(60-150m/min).
We have more than ten years of professional experience in printing machines manufacturing, in support of professional engineers and workers ,we provide high quality, best cost-effective printing machine to our customers all the time.
3. Product Features
1. Suitable for paper, nonwoven fabric and most type of plastic film(PE,PP,BOPP,etc).Color’s positive and negative for 0+8,1+7,2+6,3+5,4+4.
2. Low speed and full load startup, automatic tension control, low noise.
3. Automatic meter counter reaches the set number of meters or raw interrupt will stop automatically.
4. Aluminum roller adopts Japan brand semi-sealing small bearing, flinty oxidation, static and dynamic balancing treatments are conducted low resistance and small flop.
5. The special made modulus angular gears adopted (Helical gear), accurate printing size and full printing specifications (5mm is a spec).
6. Printing rolls should keep moving while machine halted.
7. Material holder use air-shaft, frequency control of motor speed adapts to different printing speed
8. Unwinding with auto deviation correction system (EPC).
9. Optional device:
(1) UV device
(2) Corona treatment
(3) Web Video
(4) Ceramic anilox
(5) Closed scraper
(6) 1-8 colors,600mm-2000mm width of customize
1.Main Technical Parameters
Model | 1200 |
Printing Colors | 8 color |
Max. material width | 1200mm |
Suitable material | Film, Paper,nonwoven fabric and foil |
Max. printing length | 191mm-1270mm |
Mechanical speed | 100m/min |
Printing speed | 10-80m/min |
Anilox type | Ceramic anilox |
Register precision | Longitude:±0.15mm Transverse:±0.15mm |
Rewinding&unwinding diameter | 600mm/customize |
Automatic tension control | 2-30kg |
Total power | 45kw |
Total weight | 6500kg |
Size | 4.8M*2.5M*3.5M |
2.Comprehensive Description
We specialize in gravure and flexographic printing machine, with independent research and development capabilities. 8 colors stacked type high speed flexographic printing machine is our top products. It brings together all of our technological advantages, combining the strengths of gravure and flexo printing: easy platemaking, high-precision, high speed, fast drying (UV or IR), support water-based ink, widely used and so on. We have the capability to manufacture 1-8 colors & 600-2000mm flexographic printing machine(60-150m/min).
We have more than ten years of professional experience in printing machines manufacturing, in support of professional engineers and workers ,we provide high quality, best cost-effective printing machine to our customers all the time.
3. Product Features
1. Suitable for paper, nonwoven fabric and most type of plastic film(PE,PP,BOPP,etc).Color’s positive and negative for 0+8,1+7,2+6,3+5,4+4.
2. Low speed and full load startup, automatic tension control, low noise.
3. Automatic meter counter reaches the set number of meters or raw interrupt will stop automatically.
4. Aluminum roller adopts Japan brand semi-sealing small bearing, flinty oxidation, static and dynamic balancing treatments are conducted low resistance and small flop.
5. The special made modulus angular gears adopted (Helical gear), accurate printing size and full printing specifications (5mm is a spec).
6. Printing rolls should keep moving while machine halted.
7. Material holder use air-shaft, frequency control of motor speed adapts to different printing speed
8. Unwinding with auto deviation correction system (EPC).
9. Optional device:
(1) UV device
(2) Corona treatment
(3) Web Video
(4) Ceramic anilox
(5) Closed scraper
(6) 1-8 colors,600mm-2000mm width of customize
5. Packaging and shipping A. PE stretch film wrapping, corrugated cardboard protection, steel wire fixed :
C. Electronic systems and wearing parts use wooden cases:
6. Trading terms and after sales service (1) We sold machines provide at least 360 days of quality assurance, during the warranty period, we assume full responsibility for the quality.
(2) The following three cases: beyond the quality guarantee period, improper operation and man-made damage, we still provide lifetime maintenance & guidance & commissioning of after-sales Service. However, engineers need to charge service fees.
(3) The non-standard machines that we manufacture according to customer needs, for non-standard parts, we offer customization and maintenance of lifetime, but the cost may be slightly higher than the standardized parts.
(4) Trading in FOB Term; the quoted price include the full price of the machine, transported to Ningbo Port fees, customs fees. Not include shipping and insurance charges. We can handle shipping on behalf of the purchaser, the cost paid separately by the purchaser.
(5) Earthquake, shipwrecks, war and other force majeure could be the grounds of exemption for delayed or cannot fulfill. Correspondingly, the other party's corresponding liability is also exempt.
(6) Installation and commissioning are part of after-sales service, at no additional charge. If the customer requests in writing, we will send qualified and experienced engineers. The fees borne by the customer, including but not limited to: transportation costs, accommodation costs, $ 100 per day in subsidies.
(7) Under any circumstances, customer information and contract details will be kept strictly confidential. Unless the court order or the consent of the client.
(8) Matters not covered in this document, refer to "United Nations Convention on Contracts for the International Sale of Goods (1980)" the relevant provisions solution. Both China and the United States are parties to the Convention. 7. Documents A. Manuals, technical documentation, CE certificate (if required) will be sent along with the machine;
B. Bill of lading, invoices, certificates of origin (MFN certificate of origin), fumigation certificate (if required) will confirm with the client, and then sent via DHL or UPS:
5. Packaging and shipping
A. PE stretch film wrapping, corrugated cardboard protection, steel wire fixed :
B. Rubber roller, printing plate roller and spare parts, using felt and corrugated paper box:
C. Electronic systems and wearing parts use wooden cases:
6. Trading terms and after sales service
(1) We sold machines provide at least 360 days of quality assurance, during the warranty period, we assume full responsibility for the quality.
(2) The following three cases: beyond the quality guarantee period, improper operation and man-made damage, we still provide lifetime maintenance & guidance & commissioning of after-sales Service. However, engineers need to charge service fees.
(3) The non-standard machines that we manufacture according to customer needs, for non-standard parts, we offer customization and maintenance of lifetime, but the cost may be slightly higher than the standardized parts.
(4) Trading in FOB Term; the quoted price include the full price of the machine, transported to Ningbo Port fees, customs fees. Not include shipping and insurance charges. We can handle shipping on behalf of the purchaser, the cost paid separately by the purchaser.
(5) Earthquake, shipwrecks, war and other force majeure could be the grounds of exemption for delayed or cannot fulfill. Correspondingly, the other party's corresponding liability is also exempt.
(6) Installation and commissioning are part of after-sales service, at no additional charge. If the customer requests in writing, we will send qualified and experienced engineers. The fees borne by the customer, including but not limited to: transportation costs, accommodation costs, $ 100 per day in subsidies.
(7) Under any circumstances, customer information and contract details will be kept strictly confidential. Unless the court order or the consent of the client.
(8) Matters not covered in this document, refer to "United Nations Convention on Contracts for the International Sale of Goods (1980)" the relevant provisions solution. Both China and the United States are parties to the Convention. 7. Documents A. Manuals, technical documentation, CE certificate (if required) will be sent along with the machine;
B. Bill of lading, invoices, certificates of origin (MFN certificate of origin), fumigation certificate (if required) will confirm with the client, and then sent via DHL or UPS:
