1.Main Technical Parameters
A. Model (9 colors 11 units) | 1200 | Remarks |
B. Printing Cylinder Dia (mm) | 100-380 | External Dia |
C. Printing Width (mm) | 1230/1200 | Max/Effective |
D. Printing Speed (m/min) | 10-120(Test by BOPP) |
|
E. Register Precision (mm) | ≤0.10 |
|
F. Unwinding Dia (mm) | 600 | Duplex |
G. Rewinding Dia (mm) | 600 | Duplex |
H. Tension Control Range (kg) | 2-50 |
|
I. Drying Method | Electric-heating |
|
J. Total Power (kw) | 140 |
|
K. Weight (kg) | 21000 |
|
L. Overall Dimension (M) | 14.5*2.9*2.7 | Removable Transport |
2.Comprehensive Description
For gravure printer. 6-8 color & 800mm is the most common type. But today, ordinary printing, is not the high-tech industry. Limited profit margins, will be left to the industry leader. Theoretically, red, yellow, blue and black can be stacked to a variety of colors. However, if we pursue the best printing results, we need the best machines. Compared stacked color printing, the effect of spot color printing is unrivaled. We focus on technology of the R & D and manufacturing 9-13 colors & 1400mm-2200mm large printing press.
We has already produced 5 color 2000mm and 10 color 1200mm gravure printing machines, supplied to the domestic large enterprises. We have over ten years experience in manufacturing printing presses, through the EU CE certification and ISO9001: 2008 certification. We can according to customer needs, providing customized machines.
3. Product Features
(1) Duplex unwinding & rewinding, non-stop reloading
(2) Use special registration technology to reduce progressive registration errors
(3) Total printing unit (color) can be increased or decreased, not affect the registration accuracy
(4) Automatic tension control, each printing unit has a separate web guide device
(5) Computer register systems and video monitoring devices
(6) Fully automatic operation with PLC control
(7) The ups and downs of the printing cylinder and doctor blade are using pneumatic control
1.Main Technical Parameters
A. Model (9 colors 11 units) | 1200 | Remarks |
B. Printing Cylinder Dia (mm) | 100-380 | External Dia |
C. Printing Width (mm) | 1230/1200 | Max/Effective |
D. Printing Speed (m/min) | 10-120(Test by BOPP) |
|
E. Register Precision (mm) | ≤0.10 |
|
F. Unwinding Dia (mm) | 600 | Duplex |
G. Rewinding Dia (mm) | 600 | Duplex |
H. Tension Control Range (kg) | 2-50 |
|
I. Drying Method | Electric-heating |
|
J. Total Power (kw) | 140 |
|
K. Weight (kg) | 21000 |
|
L. Overall Dimension (M) | 14.5*2.9*2.7 | Removable Transport |
2.Comprehensive Description
For gravure printer. 6-8 color & 800mm is the most common type. But today, ordinary printing, is not the high-tech industry. Limited profit margins, will be left to the industry leader. Theoretically, red, yellow, blue and black can be stacked to a variety of colors. However, if we pursue the best printing results, we need the best machines. Compared stacked color printing, the effect of spot color printing is unrivaled. We focus on technology of the R & D and manufacturing 9-13 colors & 1400mm-2200mm large printing press.
We has already produced 5 color 2000mm and 10 color 1200mm gravure printing machines, supplied to the domestic large enterprises. We have over ten years experience in manufacturing printing presses, through the EU CE certification and ISO9001: 2008 certification. We can according to customer needs, providing customized machines.
3. Product Features
(1) Duplex unwinding & rewinding, non-stop reloading
(2) Use special registration technology to reduce progressive registration errors
(3) Total printing unit (color) can be increased or decreased, not affect the registration accuracy
(4) Automatic tension control, each printing unit has a separate web guide device
(5) Computer register systems and video monitoring devices
(6) Fully automatic operation with PLC control
(7) The ups and downs of the printing cylinder and doctor blade are using pneumatic control
5. Packaging and shipping A. PE stretch film wrapping, corrugated cardboard protection, steel wire fixed :
C. Electronic systems and wearing parts use wooden cases:
6. Trading terms and after sales service (1) We sold machines provide at least 360 days of quality assurance, during the warranty period, we assume full responsibility for the quality.
(2) The following three cases: beyond the quality guarantee period, improper operation and man-made damage, we still provide lifetime maintenance & guidance & commissioning of after-sales Service. However, engineers need to charge service fees.
(3) The non-standard machines that we manufacture according to customer needs, for non-standard parts, we offer customization and maintenance of lifetime, but the cost may be slightly higher than the standardized parts.
(4) Trading in FOB Term; the quoted price include the full price of the machine, transported to Ningbo Port fees, customs fees. Not include shipping and insurance charges. We can handle shipping on behalf of the purchaser, the cost paid separately by the purchaser.
(5) Earthquake, shipwrecks, war and other force majeure could be the grounds of exemption for delayed or cannot fulfill. Correspondingly, the other party's corresponding liability is also exempt.
(6) Installation and commissioning are part of after-sales service, at no additional charge. If the customer requests in writing, we will send qualified and experienced engineers. The fees borne by the customer, including but not limited to: transportation costs, accommodation costs, $ 100 per day in subsidies.
(7) Under any circumstances, customer information and contract details will be kept strictly confidential. Unless the court order or the consent of the client.
(8) Matters not covered in this document, refer to "United Nations Convention on Contracts for the International Sale of Goods (1980)" the relevant provisions solution. Both China and the United States are parties to the Convention. 7. Documents A. Manuals, technical documentation, CE certificate (if required) will be sent along with the machine;
B. Bill of lading, invoices, certificates of origin (MFN certificate of origin), fumigation certificate (if required) will confirm with the client, and then sent via DHL or UPS:
