1.Main Technical Parameters
Model | 1600 |
Material Width(mm) | 1600 |
Unwinding diameter(mm) | 600 |
Rewinding diameter(mm) | 600 |
Inner diameter of unwinding&rewinding(mm) | 52&76 (2&3 inch) |
Slitting precision(mm) | <0.5 |
Minimum slitting width(mm) | 20 |
Speed(m/min) | 5-200 |
Slitting blades | Straight/ circular |
Total power(kw) | 4.5 |
size(M) | 1.8*2.3*1.6 |
Weight(kg) | 2500 |
2.Comprehensive Description
This model is specifically designed for BOPP and can also be used for other flexible packaging materials such as PE, PET, and PVC. Cast steel structure with a very good stability in high-speed operation. It is equipped with photoelectric web guide and automatic tension control system, the slitted surface as neat as the mirror.
3. Product Features
(1) Main drive adopts inverter control motor, the unwinding and rewinding uses magnetic powder to control the tension
(2) Photoelectric correction system with precision screw motor, slitting error of less than 0.5mm
(3) Double toolholder for loading flat blades & round blades, suitable for a variety of flexible packaging materials
(4) A-B horizontal structure, for a wide range, can be used for a variety of flexible packaging materials
(5) Integrated control, easy control, requires only one worker to operate
4. Details and photos
1. Every detail will be described in detail by text and pictures, as confirmation.
2. We provide customized manufacture according to customer demand.
3. manufactured in accordance with European CE safety standards.
A. Main drive adopts inverter control motor, the unwinding and rewinding uses magnetic powder to control the tension:
B. Photoelectric correction system with precision screw motor, slitting error of less than 0.5mm:
C. Double toolholder for loading flat blades & round blades, suitable for a variety of flexible packaging materials:
D. A-B horizontal structure, for a wide range, can be used for a variety of flexible packaging materials:
E. Integrated control, easy control, requires only one worker to operate:
Through this link, to view the video of the machine running:
https://youtu.be/iWhh8oydu-8
https://youtu.be/t7iq0CtJc3o
5. Packaging and shipping
A. We will provide free spare parts / wearing parts with the machine, customers do not need to worry about after-sales service:
B. Brush anti-rust oil is necessary before the shipment, to ensure that the machine does not rust in transit:
C. A dedicated toolbox will also be sent along with the machine, enough to meet the small size of the mechanical repairs:
6. Trading terms and after sales service
(1) We sold machines provide at least 360 days of quality assurance, during the warranty period, we assume full responsibility for the quality.
(2) The following three cases: beyond the quality guarantee period, improper operation and man-made damage, we still provide lifetime maintenance & guidance & commissioning of after-sales Service. However, engineers need to charge service fees.
(3) The non-standard machines that we manufacture according to customer needs, for non-standard parts, we offer customization and maintenance of lifetime, but the cost may be slightly higher than the standardized parts.
(4) Trading in FOB Term; the quoted price include the full price of the machine, transported to Ningbo Port fees, customs fees. Not include shipping and insurance charges. We can handle shipping on behalf of the purchaser, the cost paid separately by the purchaser.
(5) Earthquake, shipwrecks, war and other force majeure could be the grounds of exemption for delayed or cannot fulfill. Correspondingly, the other party's corresponding liability is also exempt.
(6) Installation and commissioning are part of after-sales service, at no additional charge. If the customer requests in writing, we will send qualified and experienced engineers. The fees borne by the customer, including but not limited to: transportation costs, accommodation costs, $ 100 per day in subsidies.
(7) Under any circumstances, customer information and contract details will be kept strictly confidential. Unless the court order or the consent of the client.
(8) Matters not covered in this document, refer to "United Nations Convention on Contracts for the International Sale of Goods (1980)" the relevant provisions solution. Both China and the United States are parties to the Convention.
7. Documents
A. Manuals, technical documentation, CE certificate (if required) will be sent along with the machine;
B. Bill of lading, invoices, certificates of origin (MFN certificate of origin), fumigation certificate (if required) will confirm with the client, and then sent via DHL or UPS:
