1.Main Technical Parameters
Model | 1100 |
Material Width(mm) | 1100 |
Unwinding diameter(mm) | 600 |
Rewinding diameter(mm) | 450 |
Inner diameter of unwinding&rewinding(mm) | 52&76 (2&3 inch) |
Slitting precision(mm) | <0.5 |
Minimum slitting width(mm) | 20 |
Speed(m/min) | 5-200 |
Slitting blades | Straight/ circular |
Total power(kw) | 4.0 |
size(M) | 1.8*1.7*1.6 |
Weight(kg) | 2300 |
2.Comprehensive Description
Horizontal type slitting machine is our flagship product. Horizontal cast-steel structure, unwinding and rewinding units are located at both ends of the horizontal structure. Particularly suitable for high-precision large diameter material slitting, with good stability, neat winding, and easy to control. Standard configuration includes dual optical correction and automatic tension system.
The nature of coated paper, between paper and film, is not easy to slitting. Our clients manufacture waterproof garbage bags and vomit bags. So before the delivery, we use 600mm diameter coated paper as a test material.
3. Product Features
(1) The machine adopts inverter control motor , acceleration to maintain smooth operation (also can be variable speed)
(2) Tension control, web guide and the meter counter are automated & settable
(3) Loading and unloading using A-B air shaft structure, easy and quickly
(4) Double toolholder for loading flat blades & round blades, suitable for a variety of flexible packaging materials
(5) Automatic waste edge collection & blowing out device
5. Packaging and shipping
A. PE stretch film wrapping, corrugated cardboard protection, steel wire fixed:
B. Spare parts and wearing parts using separate packages:
C. We offer wooden case or wooden pallets packaging, according to customer requirements:
6. Trading terms and after sales service
(1) We sold machines provide at least 360 days of quality assurance, during the warranty period, we assume full responsibility for the quality.
(2) The following three cases: beyond the quality guarantee period, improper operation and man-made damage, we still provide lifetime maintenance & guidance & commissioning of after-sales Service. However, engineers need to charge service fees.
(3) The non-standard machines that we manufacture according to customer needs, for non-standard parts, we offer customization and maintenance of lifetime, but the cost may be slightly higher than the standardized parts.
(4) Trading in FOB Term; the quoted price include the full price of the machine, transported to Ningbo Port fees, customs fees. Not include shipping and insurance charges. We can handle shipping on behalf of the purchaser, the cost paid separately by the purchaser.
(5) Earthquake, shipwrecks, war and other force majeure could be the grounds of exemption for delayed or cannot fulfill. Correspondingly, the other party's corresponding liability is also exempt.
(6) Installation and commissioning are part of after-sales service, at no additional charge. If the customer requests in writing, we will send qualified and experienced engineers. The fees borne by the customer, including but not limited to: transportation costs, accommodation costs, $ 100 per day in subsidies.
(7) Under any circumstances, customer information and contract details will be kept strictly confidential. Unless the court order or the consent of the client.
(8) Matters not covered in this document, refer to "United Nations Convention on Contracts for the International Sale of Goods (1980)" the relevant provisions solution. Both China and the United States are parties to the Convention. 7. Documents A. Manuals, technical documentation, CE certificate (if required) will be sent along with the machine;
B. Bill of lading, invoices, certificates of origin (MFN certificate of origin), fumigation certificate (if required) will confirm with the client, and then sent via DHL or UPS:
