1.Main Technical Parameters
Model | 50-600 | 55-800 |
Diameter of screw(mm) | 50 | 55 |
Screw ratio(L/D) | 28:1 | 28:1 |
Speed of Screw(r/min) | 10-100 | 10-100 |
Power of Main Motor Max Output | 7.5/11kw 35kg/h | 11/15kw 50kg/h |
Max.Folding width of film(mm) | 600 | 800 |
Single-sided thickness of film(mm) | 0.01-0.08 | 0.01-0.08 |
Total power(kw) | 22 | 28 |
Total weight(kg) | 1800 | 2200 |
Overall Dimensions(mm) | 1850 * 1900 * 3200 | 2100 * 2150 * 3200 |
2.Comprehensive Description
PE/HDPE/LDPE mini blown film machine is suitable to produce various of plastic film as Polyethylene (PE), Low Density Polyethylene (LDPE), High Density Polyethylene (HDPE), Linear Low-Density Polyethy -lene (LLDPE) , ETC.
The advantage of this model is: small footprint, full-featured, simple operation and stable running. Designed for small flexible packaging industry. It can connect a small flexographic printing press, used for the production of plastic bags, packaging film, decoration film.
3. Product Features
(1) The extruder barrel and screw are use of high quality alloy steel,which deal with Nitride and precision treatment
(2) The assist machine has a working platform to make the operation easy
(3) Using torque motor for rewinding, can keep proper tension and make rewinding roller more flat and easy to change
(4) Small footprint, simple operation, can connect using with a small flexographic printing machine
(5) Integrated design, foldable structure, easy to operate and move
4. Details and photos
1. Every detail will be described in detail by text and pictures, as confirmation.
2. We provide customized manufacture according to customer demand.
https://youtu.be/r9_2EJvit6A
5. Packaging and shipping A. PE stretch film wrapping, corrugated cardboard protection, steel wire fixed :
C. A 20-foot container, just to accommodate 3 machines Based save shipping costs, our long-term customers are mostly a purchase of multiple of 3. In this case, we are happy to offer some discounts :
6. Trading terms and after sales service (1) We sold machines provide at least 360 days of quality assurance, during the warranty period, we assume full responsibility for the quality.
(2) The following three cases: beyond the quality guarantee period, improper operation and man-made damage, we still provide lifetime maintenance & guidance & commissioning of after-sales Service. However, engineers need to charge service fees.
(3) The non-standard machines that we manufacture according to customer needs, for non-standard parts, we offer customization and maintenance of lifetime, but the cost may be slightly higher than the standardized parts.
(4) Trading in FOB Term; the quoted price include the full price of the machine, transported to Ningbo Port fees, customs fees. Not include shipping and insurance charges. We can handle shipping on behalf of the purchaser, the cost paid separately by the purchaser.
(5) Earthquake, shipwrecks, war and other force majeure could be the grounds of exemption for delayed or cannot fulfill. Correspondingly, the other party's corresponding liability is also exempt.
(6) Installation and commissioning are part of after-sales service, at no additional charge. If the customer requests in writing, we will send qualified and experienced engineers. The fees borne by the customer, including but not limited to: transportation costs, accommodation costs, $ 100 per day in subsidies.
(7) Under any circumstances, customer information and contract details will be kept strictly confidential. Unless the court order or the consent of the client.
(8) Matters not covered in this document, refer to "United Nations Convention on Contracts for the International Sale of Goods (1980)" the relevant provisions solution. Both China and the United States are parties to the Convention. 7. Documents A. Manuals, technical documentation, CE certificate (if required) will be sent along with the machine;
B. Bill of lading, invoices, certificates of origin (MFN certificate of origin), fumigation certificate (if required) will confirm with the client, and then sent via DHL or UPS:
